80km FTLX1812M3BTL Small Form Factor 10Gb/s (XFP) transceiver complies with the current XFP Multi-Source Agreement (MSA) Specification. They are a true multi-protocol transceiver complying with 80km SONET OC-192 and SDH STM-64 per ITU-T G.959.1: P1L1- 2D2, and also support 10GBASE-ZR/ZW 80km 10-Gigabit Ethernet, 10-Gigabit Fibre Channel 1200-SM-LL-L, and all ITU-T G.709 OTN/FEC (protocols up to 11.32Gb/s. The transceiver is also capable of supporting 8GFC, 800-SM-LC-L, with full compliance to the Tx & Rx electrical jitter specifications by adjusting a “rate select” bit through the I2C interface. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA. The transceiver is RoHS compliant and lead-free per Directive 2002/95/EC3.
Features
- Supports 8.5Gb/s to 11.3Gb/s bit rates
- Hot-pluggable XFP footprint
- Maximum link length of 80km
- RoHS-6 compliant (lead-free)
- Temperature-stabilized EML transmitter
- Duplex LC connector
- Power dissipation <3.5W
- Built-in digital diagnostic functions
- XFI Loop-back Support
- CDR bypass mode for <8Gb/s or legacy 8GFC XFP applications
- Temperature range: -40°C to 85°C
