RGBlink X2-Compact Broadcasting Quality Mixed Signal Video Wall Processor

Contact us on team@bvmindia.in and Call: +91-9205161813

Category:

X2 is a multiple output video processor, offering up to 16 outputs via four card-frame style slots. Output signal choices include HDMI, 3G-SDI, HDBaseT and H.264. On the input side there are similarly four slots, supporting up to a total of 16 video inputs. Options for input include VGA, CVBS, USB Media, 3G-SDI, HDBaseT as well as a multi-signal 4K in option.

X2 combines truly seamless, fade in fade out, glitch-free switching with advanced scaling technologies to meet the requirements of high quality, high resolution video applications, and with multi-mode operations built right in, X2 can equally be used as a video wall processor, a presentation processor or a dynamic router.

EDID management is built in enabling wide signal support, and faciliting any-signal cross-conversion for output. Real-time resolution adaptation, color uniformity compensation technology are also on board.

From the front panel operation check status and set IP address, them connect remotely over a LAN to XPOSE for dynamic over-the-wire configuration of X2

X2 is a powerful yet economical solution, ideal for video wall applications, supporting multi-window, multi-layer video configurations across the output pixel space.





SPECIFICATION



Connectors Input 4 slots, up to 16 inputs
Select from HDMI 2K Module 4 x HDMI
3G SDI  Module 4 x BNC
USB Module 4 x USB
CVBS Module 4 x BNC
VGA Module 3 x DB15
H.264 Input Module 4 x RJ45
4K@30 Module 1 x HDMI-A&LOOP | 1 x DP&LOOP
HDbaseT Module 4 x R45
Output 4slots, up to 16 outputs
Select from HDMI 1.3 Module 4 x HDMI-A
3G SDI Module 4 x BNC
HDbaseT Module 4 x RJ45
H.264 Module 1 x HDMI-A | 2 x RJ 45
PVW H.264/HDMI 1 x HDMI-A | 2 x RJ 45
Communication ULink In | Out 2 x 3.5mm Jack
LAN 1xRJ45
Genlock/Sync 1 x BNC | 1 x HDMI-A
Power 2 slots, up to 2 power inputs 1 x IEC (Each PSU)
Performance Input
Resolutions		 SDI
SMPTE 480i | 576i | 720p@50/60 | 1080i@59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 |
1080psf@23.98/24/25/29.97/30 /50/59.94/60
HDMI | USB
SMPTE 480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@50/59.94/60
VESA 800×600@60 | 1024×768@60 | 1280×768@60 | 1280×1024@60 | 1600×1200@60 | 1920×1200@60 | 2048×1152@60 |
2560×816@60
HDBaseT
SMPTE 720p@50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60
VESA 800×600@60 | 1024×768@60 | 1280×768@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 | 1366×768@60 |
1400×1050@60 | 1400×900@60 | 1680×1050@60 | 1600×1200@60 | 1920×1080@60 | 1920×1200@60 |
2048×1152@60 | 2560×812@60 | 2560×816@60
VGA
VESA 800×600@60 | 1024×768@60 |  1280×1024@60 | 1366×768@60 | 1440×900@60 | 1600×1200@60| 1920×1080@60
HDMI1.4 | DP 1.1a
SMPTE 480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@50/59.94/60 | 2160p@30
VESA 3840×2160@24 | 3840×2160@25 | 3840×2160@30
CVBS
SMPTE 480i|576i
H.264
VESA 176×144@60 | 240×180@60 | 320×180@60 | 320×256@60 | 352×226@60 |352×480@60 | 400×224@60 | 400×322@60 |
480×270@60 | 480×320@60 |480×360@60 | 480×384@60 | 480×480@60 | 544×480@60 |608×448@60 | 640×360@60 |
704×576@60 | 720×480@60 | 720×540@60 | 720×576@60 | 850×480@60 | 1024×576@60 | 1280×720@60 |
1680×1056@60 | 1920×1080@60
Output
Resolutions		 Select from below or configure customized
SDI
SMPTE 720p@50/59.94/60 | 1080i@50/59.94/60 | @1080p@50/59.94/60
HDMI
SMPTE 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@50/59.94/60
VESA 800×600@60 |1024×768@60/75/85 |1280×720@50/59.94/60 |1280×800@60 | 1280×960@60 | 1280×1024@60/75/85 |
1400×1050@60 |1600×1200@60 | 1920×1080@23.98/24/25/29.97/30/50/59.94/60 |2048×1152@60
H.264 176×144@60 | 240×180@60 | 320×180@60 | 320×256@60 | 352×226@60 |352×480@60 | 400×224@60 | 400×322@60 |
 480×270@60 | 480×320@60 |480×360@60 | 480×384@60 | 480×480@60 | 544×480@60 |608×448@60 | 640×360@60 |
704×576@60 | 720×480@60 | 720×540@60 | 720×576@60 | 850×480@60 | 1024×576@60 | 1280×720@60 |
1680×1056@60 | 1920×1080@60
Supported
Standard		 HDMI 1.4 VGA UXGA
DP 1.1a HDbaseT 1.1
USB 2.0
SDI SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI
Grey Level 10 bit
Features Max Numbers
of Layers		 16
Splicing 16k2k
Remote Control  XPOSE (Windows/MacOS) | OpenAPI | T Series Console
Power Input Voltage 100V-240V 50/60-Hz auto ajusted
Max Power 200W
Enviroment Temperature 0℃～40℃
Hudmidity 10%~85%
Physical Weight Net 12kg
Package 18kg
Dimension Net 484mm*413mm*91mm
Package 630mm*595mm*255mm
