RGBlink ASK nano puts the power of collaboration in your pocket with HDMI stocks and dongles that make screen sharing for laptops, tablets and mobile devices more convenient than ever. Simply connect a compact ASK nano TX transmitter to a Windows or macOS computer for fast, driver free connection to an ASK nano RXreceiver display – no lag, high frame rate, full rich colour video without compression. ASK nano goes anywhere with no fuss wireless video sharing on demand everywhere.
Key Features
- Up to 40m between laptop and connected display
- Self-powered on most laptops
- Compact and discrete
- Plug-and-Play – no drivers required
- Support for Windows, macOS, iOS and Android screen sharing
- Low latency
- ASK nano support audio transmission (HDMI embedded)
SPECIFICATIONS
| Receiver | ||||||||
| Connectors | Output | HDMI | 1×HDMI-A | |||||
| Power | USB | 1×microUSB | ||||||
| Performance | Output Resolutions | HDMI | ||||||
| VESA | up to 1920×1080@60 | |||||||
| Supported Standards | HDMI | 1.3 | ||||||
| Power | Input Voltage | DC 5V/500mA | ||||||
| Max Power | 2.5W | |||||||
| Environment | Temperature | -0℃～70℃ | ||||||
| Humidity | 10%~85% | |||||||
| Physical | Weight | Net | 0.026kg | |||||
| Packaged | 0.41kg (TX*2+RX*1) | |||||||
| Dimension | Net | 73.8mm×32mm×13mm | ||||||
| Packaged | 173mm×120mm×52mm(TX*2+RX*1) | |||||||
| Transmitter | ||||||||
| Connectors | Input | HDMI | 1×HDMI-A | |||||
| Power | USB | 1×microUSB | ||||||
| Performance | Input Resolutions | HDMI | ||||||
| VESA | 720×480@50/60 | 720×576@50/60 | 1920×1080@24/30/50/60 | |||||||
| Supported Standards | HDMI | 1.3 | ||||||
| Power | Input Voltage | DC 5V/500mA | ||||||
| Max Power | 2.5W | |||||||
| Environment | Temperature | -0℃～70℃ | ||||||
| Humidity | 10%~85% | |||||||
| Physical | Weight | Net | 0.027kg | |||||
| Packaged | 0.41kg(TX*2+RX*1) | |||||||
| Dimension | Net | 73.8mm×32mm×13mm | ||||||
| Packaged | 173mm×120mm×52mm(TX*2+RX*1) | |||||||
