The Plugable USB-C Docking Station with Power Delivery (UD-CA1A) increases the functionality, usability, and flexibility of supported USB-C systems like the Dell XPS 13 and XPS 15.
Power up your productivity with the ability to add an external HDMI display while simultaneously providing up to 60W of power to charge your system and expanding your connectivity with Gigabit Ethernet, audio input/output, and five USB ports to connect your peripherals. All through a single USB-C cable.
The HDMI and charging functions of the UD-CA1A are powered by one of USB 3.1’s most exciting new features: support for “Alternate Modes” and Power Delivery. Alternate Modes allow certain non-USB data and protocols (such as native video) to be sent over a USB-C cable, while Power Delivery enables you to power and charge a supported system without the need for the laptop’s proprietary charger. Support for these features must also be built-in to the system being used, so please see the important additional compatibility details in the sections below.
Important Compatibility Details
Not all USB-C ports are created equally
USB-C is a new standard with much versatility. As a result, compatibility information is complex. Some USB-C systems support Alt Mode video output, while others do not. Some can be powered and charged via USB-C Power Delivery, while others do not.
Please refer to your user manual or system manufacturer to verify that the USB-C port supports video data and charging.
USB 3.1 Type-C Compatibility
Many current USB-C systems which do support Alt Mode video output do not support charging via USB-C. Systems such as this will output video from the dock, but will still need their proprietary OEM chargers. For example, some systems will display a warning during boot if connected to a 85W power adapter rather than a 130W power adapter. These systems may still charge, but at a slower rate.
- Thunderbolt 3 ports generally support Alt Mode video output, but Power Delivery/charging is system-specific
- ASMedia USB 3.1 controllers do not support Alt Mode and are not supported
- Refer to your user manual to verify the USB-C port supports video data and charging
Plugable USB-C Docking Station with USB Power Delivery
The UD-CA1A powers up your productivity with the following features:
- Drive a single HDMI display output as a maximum resolution of 4K 30Hz (2560×1600 and lower @ 60Hz) on compatible* USB-C Alt Mode systems
- Keep your compatible* USB-C or Thunderbolt 3 system host system charged with 60W of power
- Enjoy a variety of USB connectivity with five total USB ports
- Stay connected with a wired Gigabit Ethernet port
- Make use of your headphones or microphone with audio input and output ports
- Flexible for your work space with included stand to use the dock in a vertical orientation.
Features
- FEATURES—The Plugable UD-CA1A is PCMag.com Editors’ Choice award-winning Universal USB 3.1 Type-C docking station with Power Delivery. 4K-capable HDMI display (4K at 30Hz, 2560×1600 and lower at 60Hz). Provides 60W of power to charge your attached system
- COMPATIBILITY—Single display docking expand the functionality of Thunderbolt 3 and USB-C systems. Compatible with MacBook Air 2018, MacBook Pro (2016/2017/2018), Chromebook, Microsoft Surface Go, HP Spectre x360 13″, and Dell XPS (9360, 9560, 9370, 9570, 9380). See Technical Specifications PDF below for details
- FLEXIBILITY—USB 3.1 enables charging and video output. USB C dock with charging at 60W provided via USB-IF Power Delivery (“PD”) standard. HDMI output is through “VESA DisplayPort Alternate Mode over Type-C” (“Alt Mode”). Host system must also be compatible with these technologies
- NOTES—Requires compatible USB 3.1 Type-C system. Incompatible with legacy USB 3.0 and 2.0 systems. Not all USB-C ports and systems support PD or Alt Mode. Please see our website for additional compatibility tables. DisplayPort monitors are not supported
- 2 YEAR WARRANTY—We love our Plugable products, and hope you will too. All of our products are backed with a 2-year limited parts and labor warranty as well as Seattle-based email support.
Specifications
In The Box
| Item and Quantity | Item Notes |
|---|---|
| 1x Plugable USB-C Docking Station with Power Delivery/Charging | |
| 1x USB-C to USB-C Cable | |
| 1x 80W Power Adapter | Region-specific power outlet adapters are included for purchases in the UK, EU and AUS. |
| 1x Detachable Stand | |
| 1x Quick Start Guide |
Video
| Port | Placement | Specification | Max Resolution and Refresh Rate | HDCP | Chipset |
|---|---|---|---|---|---|
| 1x HDMI 4K (Output) |
Rear | HDMI 1.4 | 3840×2160 @ 30Hz |
Host Dependent |
Audio
| Port | Placement | Connection | Max Bit Depth and Sample Rate | Signal Output | Channels | Chipset |
|---|---|---|---|---|---|---|
| Headphone Jack Output |
Front | 3.5mm (TRS) | 16-bit 48KHz | Analog | 2 | |
| Microphone Jack Input |
Front | 3.5mm (TRS) | 16-bit 48KHz | Analog | 2 | |
| HDMI 4K Output |
Rear | HDMI | Host Dependent | Digital | Host Dependent |
Power
| Port | Placement | Power Host / Device | Connection Type | Notes | Voltage | Amperage | Wattage |
|---|---|---|---|---|---|---|---|
| Power Supply | Rear | Device | Region-specific Power Adapter | UL 60950-1 Certified | 20.0V | 4.0A | 80.0W |
| USB-C to Host | Rear | Host | USB-C Power Delivery | Check Compatibility Table | 20.0V | 3.0A | 60.0W |
USB To Devices
| Port | Placement | Version and Link Rate | Features | Voltage | Amperage | Wattage |
|---|---|---|---|---|---|---|
| 3x USB-A | Front | USB 3.0 (5Gbps) | 5V | 900mA | 4.5W | |
| 2x USB-A | Rear | USB 2.0 (480Mbps) | 5V | 500mA | 2.5W |
Connection To Host
| Port | Placement | Version and Link Rate | Features |
|---|---|---|---|
| 1x USB-C | Rear | USB 3.0 (5Gbps) | USB Power Delivery |
Wired Network
| Port | Placement | Version and Link Rate | Features | Chipset |
|---|---|---|---|---|
| Gigabit Ethernet | Rear | 1000BASE-T | RTL8153 Realtek |
Included Cables
| Port Type (Side 1) | Cable Specification | Port Type (Side 2) | Cable Length | External Power for Cable |
|---|---|---|---|---|
| 1x Male IEC Type B | 1x Male IEC C5/C6 | 1.8m/6.0ft | ||
| 1x Male USB-C | USB 3.0 (5Gbps) | 1x Male USB-C | 0.5m/1.5ft | No |
