Finisar’s FTLF8536W4BTV SFP+ transceivers are designed for use in 25Gb/s data rate over
multimode fiber. They are compliant to IEEE802.3by, SFF-8472 Rev 12.2b and SFF-8402g, and compatible with SFF-8432aand applicable portions of SFF-8431 Rev. 4.1c. The transceiver is RoHS compliant and per Directive 2011/65/EUd. See Finisar Application Note AN-2038 formore details.
PRODUCT FEATURES
Up to 25.78 Gb/s bi-directional
data links
Hot-pluggable SFP+ footprint
Built-in digital diagnostic functions
850nm Oxide VCSEL laser transmitter
Duplex LC connector
RoHS compliant
100m over M5F MMF (50/125 um OM4)
70m over M5E MMF (50/125um OM3)
20m on MMF (50/125m OM2)
Metal enclosure, for lower EMI
1.2W maximum power consumption
Single 3.3V power supply
Operating temperature range:
-40°C to 85°C
APPLICATIONS
25GE SR/eCPRI
CPRI option 10, 7 , 8
100GE SR fan out to 4x25GE SR
