ADDERLink DV100 { Best Price in India } – Distributor/Dealer

ADDERLinkALDV100P-Pixel-perfect digital video extension with simultaneous audio via an HDMI connection. Distributing content in line with the High-bandwidth Digital Content Protection (HDCP) standard to enable uninterrupted extension across distances of up to 50m over a single CATx cable

Contact us on team@bvmindia.in and Call: +91-9205161813

Category:

ADDERLink® DV100 – HDMI is an easy to install, highly compact digital video extender system capable of transmitting an HD video stream with simultaneous audio over a single CATx cable via HDMI connection. Allows you to locate your media playback hardware in a secure and temperature-controlled environment. Your valuable systems are kept safely away from the display point environment whilst maintaining precisely the same user experience.

  • Pixel-Perfect: delivers digital video and simultaneous audio with optimum clarity
  • Distributes the exact content seen on the local monitor: up to 50m over a single CATx cable via HDMI
  • External power supplies are not needed: energy efficient design uses less than an eighth of the power required by some competing systems
  • Small form factor dongle: ensures optimum space saving
Product codes
ALDV100P

Product Features

  • Pixel-perfect digital video: using an uncompressed communication system with zero loss of data for resolutions up to 1920 x 1200 @ 60Hz (WUXGA)
  • Digital audio: Supports 8 channels of HDMI audio
  • Support for HDCP: in line with the High-bandwidth Digital Content Protection (HDCP) of the HDMI standard, to prevent the interruption of data flow
  • Video, audio and power share a single cable of up to 50m: distribution up to 50m over a single CATx cable (achievable extension distance dependent on cable type and number of connection intervals)
  • High energy efficiency: power is harvested from a standard USB socket so external PSUs are not needed
  • Interchangeability amongst the ADDERLink DV family of extenders: enabling cross-connection between HDMI transmitters and DVI-D receivers
  • EDID management: Extended Display Identification Data (EDID) enables the remote system to exactly mirror the data coming from the source monitor
  • Plug and Play: ADDERLink DV100 extenders are delivered in a zero config state so they work as soon as they are connected, without the need for drivers or software
  • Robust yet lightweight: tough but light ABS enclosures along with reliable internal and external connectors to withstand environmental pressures

Specification

Audio
Audio The system delivers 8 channels of HDMI audio with sample sizes of 16, 20 or 24bit at 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, or 192kHz.

Approvals / Compliance

  • CE
  • FCC

Standards

HDMI interface The system supports resolutions such as 480p, 720p, 1080p or WUXGA (1920 x 1200) @ 60Hz (with reduced blanking) and 24bit color depth.

Hardware compatibility: All computers with HDMI connections.
Cable Guidelines

Important extension distance Information:
Recommended cables are CAT7 shielded foiled twisted pairs:

  • Daetwyler 7702 Flexible patch cable
  • Daetwyler 7120 Bulk Cable.

CAT6 (or better) shielded twisted pair cable must be used to connect the local and remote units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances.

Resolution Frequency Patch Connections Cable Type Distance
1920×1200 60Hz 0 CAT7a 50 metres
1920×1200 60Hz 0 CAT6a (shielded) 50 metres
1920×1200 60Hz 2 CAT6a (shielded) 40 metres
1920×1200 60Hz 2 CAT7a 40 metres

Note: Distances are achieved using single lengths of trunk/bulk cable. For each break/patch connection reduce distance by 5m. Preferably patch cables should be of type CAT7 and less than 2m.
