The CS-992CM Professional Tripod System from Acebil includes a 100mm CH9 fluid head, T2002C carbon fiber tripod, MS-7 mid spreader, and an S-50 carry case. The tripod features a two-stage design and Carbon Fiber construction that supports loads up to 33kg / 73lb. It provides a height range from 85-170cm / 33.5”-66.9” and comes equipped with a sliding quick-release plate and pan bar.
FEATURES
- 100mm ball
- Two Stage Carbon Fiber Tripod
- Supports loads up to 33kg / 73lb
- Height range: 85-170cm / 33.5”-66.9”
General
| Head Mount Type | 100 mm Bowl |
| Maximum Working Height | 58.7″ / 149 cm |
| Minimum Working Height | 25.2″ / 64 cm |
| Closed Length | Not Specified by Manufacturer |
| Materials | Carbon Fiber |
| Weight | 11.5 lb / 5.2 kg |
Legs
| Leg Sections | 3 |
Acebil CH9(F) Video Fluid Head (100mm Ball) Specs
Camera Plate
| Camera Plate Features | Sliding Balance Plate |
| Camera Mounting Screw | 1 x 1/4″-20 Male 1 x 3/8″-16 Male |
| Balance Plate Sliding Range | 4.7″ / 120 mm |
Head
| Base Mount | 100 mm Half Ball |
| Counter Balance | Incremental 8-Step (0 to 66 lb / 0 to 29.9 kg) |
| Bubble Level | 1 x Illuminated |
Pan & Tilt
| Drag Control | Pan: 8-Step Plus 0 Tilt: 8-Step Plus 0 |
| Vertical Tilt | +90° to -70° |
| Panning Range | 360° |
| Independent Pan Lock | Yes |
| Independent Tilt Lock | Yes |
General
| Load Capacity | 77 lb / 34.9 kg |
