RGBlink vue Broadcast PTZ Camera

Contact us on team@bvmindia.in and Call: +91-9205161813

Category:
Add whole new dimensions to capturing video presentations with RGBlink vue PTZ cameras.
Featuring advanced an ISP image processor and a 2 mega pixel sensor, vue cameras are available in a range models across 12X, 20X & 30X optical zoom and a range of output options from HDMI & SDI to H.264, H.265 & NDI.
Pan, Tilt, Zoom to capture all the action – get in even closer with 10X digital zoom, and the best video with auto focus, dynamic level adjustment (WDR) and 2D/3D Dynamic Noise Reduction (DNR) all at up to 60fps.
All vue models feature the unique TALLY crown light indicator, integrated right into the housing for 360-degree viewing. The innovative and patented RGBlink vue camera design is at home in every environment.

RGBlink Vue PoE PTZ Camera Specs



Key Specifications
Image Sensor
1/2.8″-Type CMOS
Sensor Resolution
Effective: 2.07 Megapixel
Optical Zoom Ratio
30x
Max Digital Zoom
10x
External Recording Modes
SDI/BNC / HDMI / RJ45
1920 x 1080p at 25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94/60.00 fps
1280 x 720 at 25/29.97/50/59.94 fps
IP Streaming
H.264, H.265, RTMP, RTSP
1920 x 1080
1280 x 720
Imaging
Image Sensor
1/2.8″-Type CMOS
Sensor Resolution
Effective: 2.07 Megapixel
Built-In ND Filter
None
Focus Control
Autofocus
Manual Focus
Exposure Control
Signal-to-Noise Ratio
55 dB
Minimum Illumination
0.5 Lux
White Balance
3000 to 7000K
Lens
Focal Length
5.2 to 148.4mm
Optical Zoom Ratio
30x
Max Digital Zoom
10x
Field of View
Horizontal: 58.1 to 2.14°
Maximum Aperture
f/1.3 to 4.8
Video Capture
External Recording Modes
SDI/BNC / HDMI / RJ45
1920 x 1080p at 25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94/60.00 fps
1280 x 720 at 25/29.97/50/59.94 fps
Broadcast Output
NTSC
IP Streaming
H.264, H.265, RTMP, RTSP
1920 x 1080
1280 x 720
IP Multi-Stream Support
Simultaneous
H.264, H.265: 1080p, 720p, 360p
Control
Presets
255 via IR, RS-232, VISCA
Move Speed
Pan: 0.1 to 60°/sec
Tilt: 0.1 to 30°/sec
Movement Range
Pan: 340° (-170 to 170°)
Tilt: 120° (-30 to 90°)
Tally Light
Yes
Supported Control Protocols
IP
IR
Pelco-D
Pelco-P
RS-232
RS-422
RS-485
VISCA
Interface
Video I/O
1 x BNC (3G-SDI) Output
1 x HDMI Output
1 x RJ45 Output
1 x USB-A 2.0 Output
Audio I/O
1 x 1/8″ / 3.5 mm TRS Stereo Line Input
Other I/O
1 x Block 2-Pin (RS-422, RS-485) Input/Output
1 x Mini-DIN 8-Pin (RS-232) Input
1 x Mini-DIN 8-Pin (RS-232) Output
1 x RJ45 (LAN) Input
Power
PoE Support
PoE 802.3af
Power I/O
1 x Barrel (12VDC at 1.5 A) Input
Power Consumption
Device: 12 VDC 12 W
Environmental
Operating Temperature
14 to 122°F / -10 to 50°C
Operating Humidity
20 to 80%
General
Dimensions (W x H x D)
7.4 x 7.8 x 7.1″ / 18.8 x 19.8 x 18 cm
Weight
60.0 oz / 1.7 kg
Packaging Info
Package Weight
6.3 lb
Box Dimensions (LxWxH)
12.5 x 10 x 9″
