The E-TBT-FRL-05 is a stand-alone media converter that provides an interface between 10Base-T ports and 10Base-FL ports, allowing users to integrate fiber optic cabling into 10Base-T copper environments. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
Features
- Auto-MDI/MDIX
- Link Pass Through
- Automatic Link Restoration
- Integrate mixed cabling environments using either switched or shared Ethernet
E-TBT-FRL-05 Series Tech Specs
Standards
- IEEE 802.3
- 10Base-T
- 10Base-FL
Switch
- S1: Enables/disables Link Pass Through
Status LEDs
- PWR (Power): ON = connection to external AC power
- Link: ON = unit is receiving link pulses from a compliant device
- RX (Receive): ON = packets are being received
Dimensions
- Width: 3″ [76 mm]
- Depth: 3.9” [99 mm]
- Height: 1″ [25 mm]
Power Supply
- External AC/DC required; 12 VDC, 0.5A, unregulated, standard
Environment
- Operating: 0°C to 50°C
- Humidity: 5% to 90% (non-condensing)
- Altitude: 0 – 10,000 ft.
Weight
- 2 lbs. [0.90 kg]
MTBF
- 54,337 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
- 131,255 hours (Bellcore7 V5.0)
Certifications
- Safety: Wall Mount Power Supply: UL Listed, cUL Listed (Canada)
- Regulatory: FCC Class A, CISPR22/EN55022 Class A, EN55024, EN61000, CE Mark
