The GCS1716 KVM is a combo switch allowing access and control of up to 256 computers from a single console (keyboard, mouse,
and monitor). As many as 16 additional switches can be cascaded bringing the total number of connected computers to 256
computers that can be controlled from a single keyboard-monitor-mouse console. A custom ASIC (patent pending) provides an autosensing function that recognizes the position of each station on the installation, eliminating the need to manually set the position with DIP switches. Additionally, the GCS1716 features high density SPHD 15-pin instead of the usual 25-pin connectors thus allowing for
a compact design and installation in a 1U system rack.
The GCS1716 includes one USB port located on the front panel for easy access and sharing of any USB peripherals. Setup is fast
and easy; plugging cables into their appropriate ports is all that is needed. The switch supports both USB and PS/2 connections for
the console and computers. The GCS1716 intercepts keyboard input directly, thus eliminating the need for any software
configuration. Switching between computers can be easily accomplished either by manually pressing the front panel push button port
LEDs, entering hotkey combinations from the keyboard, or via a menu driven multilingual on-screen display (OSD) system. A
convenient auto-scan feature permits automatic scanning and monitoring of activities on all connected.
- Multi-platform OS support – Windows®, Mac, Sun Solaris™, and
Linux® - Auto Scan Mode to monitor connected computers
- Broadcast Mode to send commands to all connected computers
- Easy to operate – computer selection via front panel LED’s, intuitive
OSD (on screen display), and hotkeys - *Cascade up to 2 levels – control up to 256 computers from a single
console - Security – 2 level password protection for OSD
- Maximum video resolution: up to 2048 x 1536
- Supports both USB and PS/2, VGA computers
- ** Front USB Port – Fully compliant with USB 1.1 for system upgrades
and shared peripherals - Rack mountable in a 19″ (1U) system rack
- Custom ASIC provides an auto-sensing function that recognizes the
- position of each station on the installation
Fully Supports DDC2B
** Only systems connected with the USB KVM cables will be able to access
the front USB port for system upgrades and shared peripherals.
