8-Port DVI & VGA KVMP Switch
IOGEAR’s 8-port USB DVI VGA KVMP Switch allows access and control of up to 8 computers from a single USB keyboard, USB
mouse, and either a DVI or VGA monitor console. Experience superior Dual-Link video resolution up to 2560×1600 with the freedom
of choosing either DVI or VGA interface.
Expanded Connectivity
Control a connection of up to 512 computers by cascading 3 levels of this 8-Port USB DVI & VGA KVMP from a set of console. The
built-in USB 2.0 hub allows peripheral sharing between the connected system, backwards compatible with USB 1.1.
- One USB console controls eight DVI or VGA computers
- Supports both digital (DVI), analog (DVI) video and analog (VGA)
- Superior video quality: 2560×1600 (Dual Link DVI), 1920×1200
(Single Link DVI), 2048×1536 (VGA); DDC2 - Supports widescreen resolutions
- Multiplatform support – Windows, Linux, Mac, Sun
- Computer selection via front panel pushbuttons, hotkeys, and onscreen display (OSD)
- Includes two USB 2.0 peripheral sharing ports
- Independent switching of KVM and USB focus
- Two-level (Administrator / User) password authorization for enhanced
security protection - Cascadable to three levels – control up to 512 computers
- IOGEAR’s DynaSync* technology reads and remembers the
monitor’s parameters (EDID) so there is no delay or change of video
resolution when switching between, or booting computers
- Audio enabled – Full bass response provides a rich experience for 2.1
channel surround sound systems - Complete keyboard emulation for error-free booting
- Console mouse port emulation/bypass feature supports most mouse
drivers and multifunction mice - Mac / Sun keyboard support and emulation**
- Auto Scan Mode for monitoring all computers
- Broadcast mode – allows you to send commands from the console to
all computers to perform operations simultaneously - Firmware upgradable
- HDCP compatible
- Console audio ports on front panel for easy access
*IOGEAR’s DynaSync provides the EDID support for Windows 7
**Note: PC keyboard combinations emulate Mac / Sun keyboards; Does not
emulate Mac / Sun keyboard to PC keyboard
