IOGEARz’s GCL1808KIT is an integrated LCD console and 8 port KVM (keyboard, video, and mouse) switch with bundled KVM
cables that offers secure access to 8 VGA, USB or PS/2 computers. It features a convenient rack mountable sliding / retractable 17″
TFT LCD active matrix monitor and keyboard with built-in touchpad for a space-saving and streamlined integration. For added
convenience it also supports an external USB mouse. An extra USB / PS/2 console port is provided on the rear panel to manage the
LCD KVM switch from an external console (monitor, keyboard, and mouse). All this in a universal 1U rack mount space.
The GCL1808KIT supports both PS/2 and USB keyboards and mice for the connected computers, and the GCL1808KIT supports
USB** peripheral devices to be used for system upgrades with the attached computers. A single GCL1808KIT can control up to 8
computers. As many as 8 additional compatible KVM switches can be cascaded to reach up to 128 computers* controlled from a
single keyboard, monitor, and mouse console with easy computer switching via front LED pushbuttons, OSD, and hotkeys.
- Integrated 8-port KVM console featuring a 17″ TFT LCD active matrix
monitor, keyboard and touchpad - 1280 x 1024 resolution on 17″ rack mount LCD provides a sharp
video display - Equipped with 4 USB & 4 PS/2 KVM Cables
- Adjustable depth to fit different sizes of racks
- Auto Scan Mode to monitor connected computers
- Broadcast Mode to send commands to all connected computers
- Multi platform OS support – Windows®, Mac, Sun Solaris™ , and
Linux® - Easy to operate – computer selection via front panel pushbutton
- LED’s, intuitive OSD (on screen display), and hotkeys
- External USB mouse port for convenience
- External USB or PS/2 with VGA Console port
- USB media port support for attached USB computers (system
upgrades, etc)** - Cascade up to 2 levels – control up to 128 computers from a single
console* - Security – 2 level password protection for OSD
- DDC Emulation – Video settings of each computer are automatically
adjusted for optimal output to the monitor - Rack-mountable in a 19″ (1U) system rack
- Custom ASIC provides an auto-sensing function that recognizes the
position of each station on the installation - Fully Supports DDC2B
- Firmware Upgradable
*Cascade with IOGEAR 8/16-Port VGA Combo KVM Switch (Model No.
GCS1808 and GCS1716)
**Only systems connected with the USB KVM cables will be able to access
the front USB port for system upgrades and shared peripherals
