Finisar’s FTLF8532P4BCV SFP+ transceivers are designed for use in Fibre Channel links up to 28.05 Gb/s data rate over multimode fiber. They are compliant with FC-PI-6a, SFF-8472 Rev 12.2c, and compatible with SFF-8432band applicable portions of SFF8431 Rev. 4.1d. The transceiver is RoHS compliant and per Directive 2011/65/EUe. See Finisar Application Note AN-2038 for more details.
PRODUCT FEATURES
Up to 28.05 Gb/s bi-directional
data links
Hot-pluggable SFP+ footprint
Built-in digital diagnostic functions
850nm Oxide VCSEL laser transmitter
Duplex LC connector
RoHS compliant
100m over M5F MMF (50/125 um OM4)
70m over M5E MMF (50/125um OM3)
20m on 50m (OM2) MMF
Metal enclosure, for lower EMI
Single 3.3V power supply
Operating temperature range:
0°C to 70°C
APPLICATIONS
Tri-Rate 8.5/14.025/28.05 Gb/s Fibre
Channel
