E N T T E C PIXELATOR MINI-70067 PIXELATOR MINI is a compact rack, surface & DIN-rail mountable, eDMX to LED pixel protocol converter capable of outputting up to 32 universes of data.

Contact us on team@bvmindia.in and Call: +91-9205161813

Category:

Control LED pixel dots and strips with ease using the Pixelator Mini LED Pixel Converter from ENTTEC. This compact device can control up to 8192 channels (2730 RGB pixels) across its eight PLink outputs with synchronization and a high refresh rate. A practical lighting control solution with up to 16 universes of Ethernet-DMX to pixel protocol conversion. You get individual port web-based configuration for protocol options, color order arrangement, pixel grouping function, wiring identification, and more. Included mounting accessories allow surface, DIN rail, and rack mounting, making the Pixelator Mini a versatile LED pixel control device. ENTTEC also includes an ELM LED mapping software license for your convenience.

Details
  • Controls up to 16 universes of pixels (2048 RGBW / 2730 RGB / 8192 W)
  • eDMX to SPI controller makes your installation run smoothly
  • Select any input universe number and assign it to any output port
  • Configurable pixel ordering
  • Pixel grouping reduces the DMX input control channel count
  • Static or DHCP network settings
  • LED indicators for status
  • Customize output protocols to suit your fixtures
  • Power options include PoE or DC 12-24V input
  • Intuitive, easy-to-use web interface
Multi-Protocol Support
  • Art-Net
  • sACN
  • ESP
Protocol Flexibility
The device can output more than 20 built-in pixel output protocols. You can even output up to two different protocols simultaneously via ports 1 to 4 and 5 to 8.
Synchronization
The Pixelator Mini features an internal buffer and sync logic to ensure all eight PLink output ports are synchronized. Besides that, ArtSync makes sure multiple devices are also synchronized, avoiding content tearing on the output of your pixels.
Protected Data Ports, Surge Protection
The unit is designed to block DC power entering each of the data ports in the case of a short circuit or incorrect wiring. Additionally, the Pixelator Mini was engineered with two layers of rock-solid surge protection for extra safety.
Compatibility
The Pixelator Mini is compatible with most LED strips and dots on the market as well as with third-party software and applications.

ENTTEC Pixelator Mini Specs

Key Specs
Inputs/Outputs
8x RJ45 Output
1x DC Barrel (Power) Input
1x RJ14 (10/100 Ethernet) Input
Channels
8192
Power Source
AC Adapter
Protocol
ArtNet, sACN, ESP, PLINK
General
Inputs/Outputs
8x RJ45 Output
1x DC Barrel (Power) Input
1x RJ14 (10/100 Ethernet) Input
Channels
8192
Dimming
Optional
Cooling System
Active
Power
Power Source
AC Adapter
Power Consumption
8 W
Input Power
12 to 24 VDC
PoE Port Power
Yes
Compatibility
Protocol
ArtNet, sACN, ESP, PLINK
Physical
Operating Conditions
32 to 122°F / 0 to 50°C up to 95% Humidity
Environmental Resistance
Dust-Resistant (IP20)
Material of Construction
Aluminum, Plastic
Rack Mount
Yes
Packaging Info
Package Weight
2.385 lb
Box Dimensions (LxWxH)
13.1 x 10.4 x 3.2″
