This 18Gbps HDMI Extender can extend HDMI and IR control signals to a distance up to 230ft / 70m via a single CAT6/6a cable, which can achieve zero-delay, uncompressed long-distance transmission between the transmitter and receiver. Video resolution is up to 4K@60Hz. It supports EDID copy pass-through function between the source device and display device, and it supports POC function.
Features
- HDMI 2.0b and HDCP 2.2 compliant
- Support 18Gbps video bandwidth
- Support up to 4K2K@60Hz RGB/YCBCR 4:4:4
- The transmission distance can be extended up to 230ft single CAT6/6a cable
- Support HDR, HDR10, HDR10+, Dolby Vision, HLG
- Support bi-directional IR control signal pass-through
- Audio formats: LPCM 7.1, Dolby True HD, DTS HD Master
- EDID copy pass-through function
- Support ARC and audio de-embedding
- Support bi-directional POC (Power over Cable) function
Applications
Used to extend HDMI or IR control signals to distances up to 230ft.
Specifications
- Extender Type – HDMI
- Spec Sheet available – Yes
- Spec Sheet available – Yes
- Operating Temperature (Maximum): 104 F
- Operating Temperature (Minimum): 32 F
- Transmission Range: 230 ft
- Active Power: 3.36 Watt
- Depth: 2.68 in
- Height: 0.71 in
- Width: 3.54 in
- Color: Black
- Current Draw: 1 Amps
- DC Voltage: 12 Volts
- HDMI Compliance: HDMI 2.0b
- HDCP Compliance: HDCP 2.2
- Video Bandwidth: 18Gbps
- Video Resolution: 4K at 60Hz
- Color Space: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
- Color Depth: 8-bit, 10-bit, 12-bit
- HDR formats: HDR, HDR10, HDR10+, Dolby Vision, HLG
- HDMI Audio Formats: LPCM 71CH, Dolby True HD, DTS-HD Master
- Optical Audio Formats: Dolby 51, DTS 51, PCM 20
- Transmitter Input ports: 1 HDMI Type A IN
- Transmitter Output ports: 1 HDMI Type A OUT, 1 CAT6/6a OUT
- Transmitter Control Ports: 1 Micro USB Service Port, 1 IR IN, 1 IR OUT
- Receiver Input ports: 1 CAT6/6a IN
- Receiver Output ports: 1 HDMI Type A OUT, 1 Toslink
- Receiver Control Ports: 1 Micro USB Service Port, 1 IR IN, 1 IR OUT
- Housing: Metal Enclosure
- Dimensions Transmitter/Receiver: 90mm(W)×68mm(D)×18mm(H)
- Weight: Transmitter: 160g, Receiver: 155g
- Storage Temperature: -20°C ~ 60°C/-4°F ~ 140°F
- Relative Humidity: 20~90% RH (non-condensing)
