CSV-6200H -The Club 3D SenseVision MST Hubs utilize Multi-Stream Transport, a unique DisplayPort™ 1.2 feature that creates the ability to transport multiple independent uncompressed displays (and audio) streams over a single cable, supporting protected content and high-performance applications such as 3D gaming. This enables the use of multiple monitors connected by MST hub configuration. The Club 3D MST Hubs is able to distribute those video streams to the connected HDMI™ screens.
The Club3D MST Hubs do not increase the bandwidth of the DisplayPort™ 1.2 output of the source system, but it enables the optimal use of it.
The CSV-6200H is Plug & Play and does not require any driver installation.
Note: When using a DisplayPort™ 1.1 video card the MST hub will act as a splitter, automatically mirroring your video source across all displays.
| Features: |
| • Compliant with: DisplayPort™ v1.2a, DisplayPort™ v1.1a, VESA DDM Standard, HDCP V2.0, Display Id,and EDID V1.4 |
| • Supports main link rates of 5.4Gbps (HBR2), 2.7Gbps (HBR) and 1.62Gbps (RBR) from source |
| • Supports HDMI™ 1.4 specifications for the 2 outputs. |
| • Input pixel data depth 6/8/10/12 bits and supports output pixel format RGB444 |
| • Supports Advanced Wide Eye™ SerDes technology enables high Jitter performance |
| • Supports AMD Eyefinity™ |
| • Compatible with Microsoft Surface Pro and Intel NUC platforms |
| • Works with AMD, Nvidia and Intel Graphics solutions |
